PILGERING

• Cold Pilgering process using full link die and tapper mandral
• To reduce the cross section  by upto 90% because the process relies on large number of small forming steps
• Cold Pilgering and are longitudinal cold rolling process that reduce the diameter and wall thickness of metal tube in one process step
• By cold Pilgering process surface finish achieved matter than cold drawing finish (Less than 0.4 micron) and improved microstructure grain size.
• Our pilgering range are OD12 to 73mm and wall thickness 0.8 to 4mm

COLD DRAWING

• In cold drawing process raw material tubes are coated with some special chemical or applied some special lubricant oil.
• The tubes are pulled through tungsten carbide die and flotting/fixed plug inside the tubes, resulting in reduced tube diameter and wall thickness corresponding increases in tube length
• Our capacity of drawing are OD 6 to 609.6mm & thickness are 0.8 to 12mm.








Specifications :
Size/Range :6mm to 323.9mm

Thickness : 0.5 mm to 12 mm

Length :Random Length 4 to 7 MTR.

Standard Fixed Length :up 28 MTR

Conditions : Hot Finish/ Cold Finish, Heat Treated & Stress Relived, Bright Annealing

Standards : ASTM A53, A106, A179, A192, A213, A210, A335G, P1, P5, P9, P11, P22, P91, T11 , T22 , T9 , T91 , A334

Radius : 1.5 D to 2 MTR. DU Bend

Grades : Carbon Steel / Alloy Steel, GR1 , GR3 , GR6
